Weld Fixture and Production Tooling
RWS designs and builds weld fixtures and production tooling for robotic welding, manual welding, brazing and repeat assemblies. Tooling is developed around the part, welding process, access requirements and production needs.
Why Fixturing Matters
What good fixturing controls
- Part location
- Joint consistency
- Weld access
- Distortion management
- Loading and unloading
- Repeatability
- Inspection access
Tooling Applications
Tooling built at RWS
Robotic weld fixtures
Fixtures built around the robotic cell, the part and torch access.
Manual weld fixtures
Fixtures for manual welding where fit-up and position need to repeat.
Brazing fixtures
Holding fixtures that keep joint clearance consistent through heating.
Assembly fixtures
Fixtures used for fitting and mechanical assembly operations.
Prototype tooling
Simple tooling to produce and review first parts.
Production tooling
Tooling built for recurring production runs.
Fixture modifications
Existing fixtures reviewed and modified for approved design changes.
Tooling in Use
Fixtured production work
Fixtured bracket assemblies
Steel bracket assembly produced as part of a repeat program at RWS.
See related workTooling Development Process
How tooling is developed
- 01
Drawing and part review
- 02
Datum and locating strategy
- 03
Weld-access review
- 04
Fixture design
- 05
Fixture build
- 06
Trial parts
- 07
First-article approval
- 08
Production release
Customer-Owned Tooling
Tooling scope and ownership
Tooling scope, ownership, storage, maintenance and any future modification requirements are defined in the quotation or project agreement for each program.
That keeps expectations clear on both sides before tooling is built, and gives you a documented reference when the design changes or the program is renewed.
